Model: K613 Automatic Cleveland Open Cup Flash Point Tester

Measures the flash point of petroleum products by Cleveland open cup. Except fuel oils and other petroleum products having an open cup flash point below 79°C.

Conforms to ASTM D92 and related specifications. CE Mark.

Big screen LCD display. Auto-heating, auto-flame applicating, auto-igniting, auto-measuring and auto-printing etc. Simple automation routine for easy operation.

Technical specification

Maximum measuring flash point: 400°C

Measuring accuracy: 0.1°C

Repeatability: flash point belows 150°C, ±2°C; flash point aboves 150°C, ±4°C

Integral forced-air cooling system

Built-in thermal printer to print out results

Ambient temperature: 10°C - 55°C

Relative humidity: 30% - 80%

Power supply: AC 220V, 50Hz

Dimensions: 450 x 370 x 300mm

Net weight : 12.5kg

If you would like to discuss your requirements for this product further, please email us at or use our enquiry form.
